ACR-130DG-22-RRC-L1 2-Section Refrigerated Counter

Refrigerated counters

The Hoshizaki ACR-130DG-22-RRC-L1 is a 2-Section Refrigerated Counter with a net internal volume of 128 l.

This refrigerated counter not only meets rigorous kitchen demands but also boosts operational efficiency with its thoughtful design and durable construction.

Get quote View spec sheet

Key features Specifications Documentation

Key features

Efficient Cooling

The climate class 5 system includes fan-assisted cooling to maintain optimal temperatures up to +40°C, ensuring food stays fresh, and features automatic defrost with re-evaporation of defrost water.

Hygienic Surfaces

Both interior and exterior are made of stainless steel, offering a robust, food-safe environment that is easy to clean and maintain.

User-Friendly Design

Features like reversible doors, anti-tilt shelves, and removable magnetic door gaskets with triple insulation facilitate seamless operation and maintenance, for a smooth kitchen workflow.

Convenient Extras

Includes a low-maintenance condenser, and a compact slide-out refrigeration unit for effortless servicing, reducing downtime and operational hassles.

Specifications

Specification	Value
Brand	Hoshizaki
Exterior	Stainless Steel
Interior	Stainless
Legs / Castors	H = 130/180 mm (L1)
Climate class	5 (max. ambient 40°C w/ 40% RH)
Insulation type	Cyclopentane
Energy efficiency class	C
Cooling system	Built-in cooling system
Country of origin	Turkey
Country of origin	Turkey
Number of sections	2 sections
Energy efficiency class standard	ISO 22041-2019
Door/drawer configuration	2 drawer section
Model name	ACR-130DG-22-RRC-L1
Item number	889000848
Equipped with	Stainless steel worktop, 2 drawer sections each with 2 x 1/2 drawers
Equipped with	Stainless steel worktop, 2 drawer sections each with 2 x 1/2 drawers
Disclaimer	Every effort has been made to ensure that the information contained in this spec sheet is accurate at the time of publishing. Hoshizaki Europe BV assumes no responsibility or liability for typographical errors or omissions or for any misinterpretation of the information within the publication and reserves the right to change without notice.
Disclaimer	Every effort has been made to ensure that the information contained in this spec sheet is accurate at the time of publishing. Hoshizaki Europe BV assumes no responsibility or liability for typographical errors or omissions or for any misinterpretation of the information within the publication and reserves the right to change without notice.
Calago Text App Result	[[apptest4\|\|none\|,\|space_symbol\|]]
Calago Text App Result	[[apptest4\|\|none\|,\|space_symbol\|]]
Optional Extras	Set of legs for 835-900 mm Counter-top (L2) Set of 4 Castors for 850 mm Counter-top (C1) Set of 4 Castors for 900 mm Counter-top (C2) Castor Extension Kit (extends height of castors by 50mm) Flat worktop with 100 mm splashback Drawer section with 3 x 1/3 drawers * * 3 drawer section is not available next to the compressor housing
Optional Extras	Set of legs for 835-900 mm Counter-top (L2) Set of 4 Castors for 850 mm Counter-top (C1) Set of 4 Castors for 900 mm Counter-top (C2) Castor Extension Kit (extends height of castors by 50mm) Flat worktop with 100 mm splashback Drawer section with 3 x 1/3 drawers * * 3 drawer section is not available next to the compressor housing
Model	1.0000

Documentation

Documentation
Declaration of conformity	Download
Dimensional drawings (main)	Download
ACR_130_DRAWERS_specsheet1.pdf	Download
Drawer_dimensions_2_2_drawer.pdf	Download
ACR_130DG_22.pdf	Download
Instruction manual	Download
Service manual	Download
Spare parts / parts list	Download
